Apply to the 3C and electronics industry.
Equipment parameters
| technical parameter | |||
| Laser type | fiber-optic laser | Laser wavelength | 1.06um |
| output power | ≥20/30/5oW MOPA laser | Laser repetition rate | 1.5-100OKHz |
| Mark range | 100*100(standard)-400*400mm2(replacement lens) | Beam quality M2 | ≤2.0 |
| light output focal length | 197mm (depending on the lens) | Engraving line speed | ≤7000mm/s |
| Lifting body specifications | 500mm manual lifting body | Repeatability | Soil 0.003mm |
| Total power | ≤0.5KW | Engraving depth | ≤0.4mm |
| Total Weight | 120KG | Minimum line width | 0.1mm |
| Power Specifications | AC220V/2.5A | Minimum character height | 0.1mm |
| operating temperature | 15℃-35℃ | Optional waveform | No. 3/No. 8 |
| Operating humidity | 10%-90% | ||
